How to Use Vision Models for Document AI

// In plain English

Traditional OCR (Optical Character Recognition) is a translator: it looks at a scanned image, recognises each character, and outputs raw text. That raw text then has to go through a second, separate system that figures out what the words mean — which number is the invoice total, which row is whose address, which column is the quantity. Two pipelines, two failure points.

A vision language model like GPT-4o, Claude, or Gemini collapses that into one step. You hand it an image of a document — a scanned invoice, a PDF slide, a photo of a handwritten form — and ask it a question in plain English: "Extract the line items as JSON" or "What is the total amount due?" The model reads the pixels, understands the layout and context, and returns a structured answer, all in a single API call.

This is called vision-based Document AI, and it has become one of the most commercially valuable uses of large multimodal models. The catch is that it requires good prompting and a realistic understanding of where these models beat traditional pipelines and where they don't.

// Why it matters

Most enterprise data is locked in documents. Invoices, contracts, medical records, insurance claims, shipping manifests, research papers — almost none of it arrives as clean, structured rows in a database. Before vision models, processing these documents at scale required:

1. An OCR engine (e.g. Tesseract, AWS Textract, Google Document AI) to extract raw text.
2. A layout parser to identify regions — headers, tables, footers — from bounding-box coordinates.
3. A custom extraction model or regex rules to pull specific fields from the extracted text.
4. Post-processing logic to validate, normalise, and handle errors.

Each stage needs maintenance, training data, and its own failure modes. Vision models replace most of that stack with a single model you instruct in natural language. For many use cases — especially those with varied document layouts or occasional handwriting — this is dramatically faster to build and easier to adapt.

• Invoice and receipt processing. Extract line items, totals, vendor names, and dates across thousands of invoice layouts with no per-layout training.
• Contract and legal document review. Find specific clauses, dates, and parties across dense multi-page PDFs.
• Medical form digitisation. Read handwritten or mixed print/handwrite patient forms into structured records.
• Research and report summarisation. Pull key figures, tables, and conclusions from academic PDFs.
• ID and credential verification. Extract fields from passports, driving licences, and ID cards.

// How it works

The basic pipeline for vision-based document extraction is straightforward. You convert your document to an image (or use the model's native PDF support where available), send that image alongside a carefully written prompt via the model's API, and receive structured text — ideally JSON — in return.

Step 1: prepare the image

Most vision model APIs accept JPEG or PNG images up to a few MB. PDFs need to be rasterised first — the pdf2image Python library (backed by Poppler) is the standard choice. Aim for 150–300 DPI for printed documents; go higher (300–400 DPI) for handwriting or small print. Too low and characters blur; too high wastes tokens and increases latency.

from pdf2image import convert_from_path
import base64, io

# Convert first page of a PDF to a base64-encoded PNG
pages = convert_from_path("invoice.pdf", dpi=200)
buffer = io.BytesIO()
pages[0].save(buffer, format="PNG")
image_b64 = base64.b64encode(buffer.getvalue()).decode()

Step 2: write a high-quality extraction prompt

The prompt is the most important variable in vision document AI. A vague instruction like "extract the data" will produce inconsistent results. A structured prompt with a clear task, an explicit output format, and a JSON schema example reliably outperforms both.

SYSTEM_PROMPT = """
You are a document extraction assistant. Extract structured data from the document image.
Return ONLY a valid JSON object matching the schema below. Do not add commentary.

Schema:
{
  "vendor_name": "string",
  "invoice_number": "string",
  "invoice_date": "YYYY-MM-DD",
  "due_date": "YYYY-MM-DD or null",
  "line_items": [
    {
      "description": "string",
      "quantity": "number",
      "unit_price": "number",
      "total": "number"
    }
  ],
  "subtotal": "number",
  "tax": "number or null",
  "total_due": "number"
}

If a field is not present in the document, use null.
"""

Step 3: call the API

The API call is the same for most providers — you pass the image as a base64 data URL alongside the text prompt. Here is an example using the Anthropic SDK:

import anthropic

client = anthropic.Anthropic()

message = client.messages.create(
    model="claude-sonnet-4-5",
    max_tokens=1024,
    system=SYSTEM_PROMPT,
    messages=[
        {
            "role": "user",
            "content": [
                {
                    "type": "image",
                    "source": {
                        "type": "base64",
                        "media_type": "image/png",
                        "data": image_b64
                    }
                },
                {
                    "type": "text",
                    "text": "Extract all invoice data from this document."
                }
            ]
        }
    ]
)

import json
result = json.loads(message.content[0].text)

// Prompting strategies that improve accuracy

The difference between a 70% and a 95% extraction accuracy often comes down to the prompt. Research and practitioner benchmarks consistently identify five techniques that move the needle:

1. Provide an explicit JSON schema

Listing the exact output schema — field names, types, and a note about nulls — reduces hallucination and schema drift. The model treats the schema as a checklist; fields that are missing from the document get null rather than a fabricated value.

2. Define entities you care about

Short, concise entity definitions outperform both no definitions and overly verbose ones. For example: "due_date: the payment deadline, printed as 'Due by' or 'Payment due'. Format as YYYY-MM-DD." This tells the model exactly which text to look for and how to normalise it.

3. One-shot or few-shot examples

Including one complete input/output example in your system prompt dramatically improves format compliance. Show a fictional document snippet alongside the ideal JSON output. The model calibrates its output format to match your example rather than guessing.

4. Ask for Markdown tables when structure matters

For table-heavy documents (financial statements, data sheets), asking the model to return a Markdown table first, then parse that table separately, can be more reliable than asking for JSON directly. The model's visual table-reading accuracy is high; JSON serialisation is where errors creep in.

5. Chain-of-thought for complex layouts

For multi-page documents or ambiguous layouts, prepend "Think step by step: first identify all sections, then extract fields from each section" to your instruction. Chain-of-thought prompting helps models navigate complex structures without jumping to conclusions.

// Choosing the right model

GPT-4o, Claude, and Gemini all perform well at document extraction, but they have different strengths. Here is a practical comparison based on 2025–2026 benchmarks and practitioner experience:

Vision models vs traditional OCR tools

Traditional OCR tools like AWS Textract, Google Document AI, and Azure Form Recognizer are purpose-built for specific document types. They are faster (milliseconds vs seconds), cheaper per page at high volume, and offer specialised extractors for common formats like W-2 forms or driving licences. Vision models beat them on flexibility — novel layouts, mixed content, reasoning questions — but lose on throughput and unit economics.

// Going deeper

Once you have a basic extraction pipeline working, there are several directions to explore depending on your use case.

Multi-page documents

For long PDFs, you have two options. Native PDF input (supported by Claude and Gemini) lets you send the entire PDF as a single API input; the model handles page segmentation internally. Page-by-page processing with aggregation gives you more control — process each page independently, then merge the JSON outputs. The latter is more predictable for very long documents and lets you parallelize requests.

Evaluation and quality measurement

Build an eval set of 50–100 documents with known ground-truth values and run your pipeline against it before going to production. Measure field-level accuracy (not just full-record accuracy), track null rates, and log confidence by document type. An LLM-as-a-judge can help grade free-text fields where exact-match comparison doesn't work.

Image pre-processing for accuracy

On scanned or photographed documents, pre-processing can significantly improve results: deskew (correct rotation), binarise (convert to black and white), and remove background noise before sending to the model. The Python opencv-python and Pillow libraries cover most of these needs. Even a simple deskew step can recover several accuracy percentage points on difficult scans.

Agentic document workflows

For complex document workflows — classify the document type, route it to a specialist extraction prompt, validate the result, then request human review if confidence is low — an AI agent with tool use is a natural fit. The vision model becomes one tool in a broader pipeline rather than the whole system.
