How to Pick Chunk Size and Overlap (with Sane Defaults)

// In Plain English

When you build a RAG system, you can't feed a 200-page PDF into an embedding model all at once. You slice it into smaller pieces — chunks — and embed each one separately. The two dials you control are chunk size (how many tokens per piece) and chunk overlap (how many tokens you repeat between neighbouring pieces).

Think of it like indexing a textbook. If every index entry points to an entire chapter, you'll find the chapter but spend ages hunting for the exact sentence. If every entry points to a single line, the index becomes enormous and each entry lacks enough context to be useful. The right granularity is somewhere in between — a paragraph or two — enough context to be self-contained, small enough to be precise.

Overlap is the equivalent of letting two consecutive index entries share a sentence or two at the boundary. It prevents an important idea that straddles a split point from falling through the cracks.

// Why It Matters

Chunk size is the single most consequential hyperparameter in a RAG pipeline. It shapes retrieval precision, answer quality, embedding cost, and vector-store size — all at once.

When chunks are too small

• Missing context. A 50-token snippet often lacks the surrounding explanation a reader needs. The retrieved chunk is technically relevant but semantically incomplete.
• Retrieval slot waste. Most RAG pipelines retrieve the top-k chunks (often k=3–5). If each chunk is tiny, you burn all your slots on fragments of the same paragraph.
• Noisy embeddings. Very short strings produce less stable embeddings because there are fewer semantic signals to average over.
• Higher cost. More chunks mean more embedding API calls at ingest time, larger vector indexes, and more tokens spent on retrieved context at query time.

When chunks are too large

• Diluted embeddings. A 2,000-token chunk covering multiple topics produces an embedding that represents an average of those topics — exact-fact queries get buried.
• Context-window pressure. Large retrieved chunks consume more of the LLM's context window, leaving less room for the model's reasoning.
• Precision loss. The answer might be in the chunk, but so is a lot of irrelevant text — the model has to sift through noise.

// How It Works

The chunking step sits at the very start of the RAG ingestion pipeline, before any embedding or indexing happens. Here is the full flow:

Fixed-size chunking with overlap

The most common approach is a sliding window. You advance through the text by chunk_size - overlap tokens at each step, so consecutive chunks share overlap tokens at the seam. LangChain's RecursiveCharacterTextSplitter and LlamaIndex's SentenceSplitter both implement this pattern.

from langchain.text_splitter import RecursiveCharacterTextSplitter

splitter = RecursiveCharacterTextSplitter(
    chunk_size=512,       # tokens (approx chars/4 for English)
    chunk_overlap=51,     # ~10 % of chunk_size
    length_function=len,  # swap for a tokenizer for exact token counts
)

chunks = splitter.split_text(document_text)
print(f"{len(chunks)} chunks, first: {chunks[0][:120]}...")

How overlap prevents context loss

Imagine a document where a key conclusion spans the boundary between chunk 3 and chunk 4. Without overlap, the embedding for chunk 3 ends mid-thought and chunk 4 starts mid-thought — neither captures the full conclusion. With 10% overlap, the last 51 tokens of chunk 3 reappear at the start of chunk 4, so at least one of the two chunks contains the complete thought.

// Sane Defaults by Use Case

There is no single universal best chunk size, but there are well-tested starting points. The table below reflects industry practice and published benchmarks as of 2025–2026:

LlamaIndex's built-in default is 1024 tokens with an overlap of 20 tokens (roughly 2%). LangChain's RecursiveCharacterTextSplitter default is 1000 characters with 200 characters overlap (~20%). Both are conservative starting points; 512 tokens / 10% overlap tends to perform better across a wider range of tasks in practice.

// How to Tune Chunk Size on Your Own Data

Defaults get you started, but the optimal chunk size is workload-specific. Here is a repeatable tuning loop you can run in an afternoon:

1. Build a small evaluation set. Write 20–50 representative questions and note which passage in your documents contains the correct answer.
2. Pick 3–5 candidate chunk sizes — for example 256, 512, 768, and 1024 tokens.
3. Ingest your documents at each chunk size into separate collections in your vector store.
4. Run retrieval-only evaluation. For each question, retrieve top-5 chunks and check whether the ground-truth passage appears. Compute hit rate (did the right chunk appear in top-5?) and mean reciprocal rank (how high did it rank?).
5. Pick the chunk size with the best hit rate. If two sizes tie, prefer the smaller one — it's cheaper and leaves more LLM context for the model to reason.
6. Tune overlap last. Start at 10%, try 5% and 20%, and re-run your eval set. You will often find overlap makes little difference on retrieval metrics but can noticeably improve answer faithfulness.

Quick sanity checks before you start

• What is the average length of a natural unit in your documents? A paragraph? A section? Aim to have each chunk contain roughly one complete unit.
• What kinds of questions will users ask? Precise lookup questions ("What is the filing date?") favour small chunks. Synthesis questions ("Summarise the risk factors") tolerate or even benefit from larger chunks.
• What is your LLM context window? With a 128k-token window you can retrieve more, larger chunks — the pressure to keep chunks tiny is lower than it was with 4k-token windows.

// Advanced Patterns: Beyond Fixed-Size Chunks

Once you have a baseline, two advanced patterns often provide measurable gains:

Parent-document retrieval (hierarchical chunking)

Store small child chunks (128–256 tokens) in the vector index for precise retrieval, but when a child chunk is retrieved, return its parent chunk (512–2048 tokens) to the LLM as context. This combines the precision of small embeddings with the coherence of large context. LlamaIndex's ParentDocumentRetriever and SentenceWindowRetrieval implement this pattern out of the box.

Recursive character splitting

Rather than cutting at a fixed token count, RecursiveCharacterTextSplitter tries a priority list of separators — \n\n (paragraph break) first, then \n, then space, then characters — and only falls back to the next separator when the current chunk exceeds the target size. This produces more semantically natural boundaries without requiring an NLP model, and it is LangChain's recommended default for most text types.

Semantic (embedding-based) chunking

Semantic chunkers embed consecutive sentences and split wherever the cosine similarity between adjacent sentence embeddings drops below a threshold. This produces topically coherent chunks regardless of character count. The trade-off: it requires running an embedding model during ingestion (slower and more expensive), and benchmarks show it does not always outperform well-tuned fixed-size chunking.

// Going Deeper

Once you have nailed chunk size and overlap, the next levers that affect retrieval quality are:

• Metadata filtering. Attach document-level metadata (source, date, section) to each chunk and filter at query time. This can be more effective than tweaking chunk size when your corpus has heterogeneous document types.
• Hybrid search. Combine dense vector search with BM25 (keyword) search and merge the ranked lists with Reciprocal Rank Fusion. Keyword search rescues chunks whose exact terminology the embedding model under-represents.
• Re-ranking. After retrieving top-k candidates, pass them through a cross-encoder re-ranker (e.g. Cohere Rerank or a local cross-encoder/ms-marco model) to re-order by relevance before sending to the LLM. This often adds more value than further chunk-size tuning.
• Contextual chunk headers. Prepend each chunk with a one-sentence summary of the document it came from before embedding. This reduces the problem of orphaned chunks that lack context when embedded in isolation — a technique popularised as "contextual retrieval" by Anthropic in 2024.
• Adaptive or multi-scale chunking. Research from AI21 Labs and others shows that different queries benefit from different granularities. Multi-scale approaches index documents at two or three chunk sizes simultaneously and route queries to the most appropriate granularity based on query type.

The key discipline is to always measure before and after any change. A retrieval eval set with 30–50 labelled questions takes an hour to build and will save you from chasing false improvements. Tools like RAGAS, TruLens, and LlamaIndex's RetrieverEvaluator make this loop repeatable.
